SMT, or Surface Mount Technology, is a widely adopted technique in the current electronic assembly industry. Its popularity stems from its high assembly density, compact size of electronic products, lightweight, and excellent high-frequency characteristics. However, the intricate processes involved in SMT assembly incorporate numerous technical terms that are crucial for beginners and general customers to understand. Here, Charmhigh Electromechanical provides a comprehensive list and detailed explanations of the common SMT assembly terminology:

SMA (Surface Mount Assembly): Refers to the printed circuit board assembly completed using surface mount technology, commonly known as component assembly on PCB boards.

Reflow Soldering: A welding technique that involves melting solder paste pre-dispensed onto PCB pads to achieve the connection between surface-mounted components and PCB pads.

Wave Soldering: A process where molten solder is sprayed through specialized equipment to form a solder wave, allowing pre-mounted electronic components on the PCB to pass through the wave, achieving a connection between components and PCB pads.

Fine Pitch: In SMT, a pin spacing less than 0.5mm is referred to as fine pitch, requiring precise processing and placement techniques.

Coplanarity: A metric measuring the vertical height deviation of surface-mounted component pins, typically not exceeding 0.1mm, which affects the contact between components and the PCB board.

Solder Paste: A mixture of powdered solder alloy, flux, and other additives used to connect electronic components to PCB pads.

Curing: The process of heating adhesive tape under specific temperature and time conditions to temporarily fix components to the PCB board.

Adhesive Tape or Red Glue: A colloidal material used in SMT processing to temporarily fix components to PCB boards, possessing strong adhesive strength after curing.

Dispensing: The process of applying adhesive tape onto PCBs to ensure stable component attachment.

Dispensing Machine: A specialized device for completing dispensing operations.

Placement: The operation of picking up surface-mounted components from feeders and accurately placing them onto specified positions on PCB boards.

SMT Carrier Tape: Used to connect feeder trays, enabling uninterrupted operation and saving time and costs.

Placement Machine: A specialized device for completing the surface mounting of electronic components.

Hot Air Reflow Soldering: A reflow soldering technique that utilizes forced circulation of hot air for heating.

Placement Inspection: Quality inspection conducted during or after placement to detect missing, misplaced, wrongly placed, or damaged components.

Stencil Printing: The process of using a stainless steel stencil to print solder paste onto PCB pads.

Stencil Cleaner: Installed on printing machines, used for automatically cleaning excess solder paste from stencils.

Printer: A specialized device used for stencil printing in SMT.

Post-Solder Inspection: Quality inspection conducted on PCBAs after soldering or curing in a reflow oven.

Pre-Solder Inspection: Quality inspection of PCBA placement conducted before soldering or curing in a reflow oven.

Rework: The repair process to remove local defects from PCBAs.

Rework Station: A specialized device for reworking PCBAs with quality defects.

Understanding these technical terms is crucial for grasping SMT assembly techniques. We hope that the explanations provided can serve as a valuable resource for your learning and practice in SMT.
